IGX-41M
IGX-41M Inverted Microscope
Price Rs. 2,35,000 to Rs. 3,75,000.
The IGX-41M is a cutting-edge metallurgical microscope designed for high-precision analysis in industrial and research settings. It features an infinity color-corrected optical system, ensuring clear and accurate imaging across all magnifications. The 45-degree inclined trinocular viewing head is rotatable 360 degrees, allowing flexible and comfortable observation from various angles. The interpupillary distance is adjustable between 50mm and 75mm, making it suitable for different users.
Equipped with high eye-point wide field plan eyepieces, the IGX-41M offers superior viewing comfort, with options for both 10X and 15X magnifications. The eyepieces are also diopter adjustable and reticle attachable, allowing for customized use based on the user’s needs.
| Category | IGX-41M Inverted Metallurgical Microscope |
|---|---|
| Optical system | Infinity color-corrected optical system |
| Viewing head | 45 degree inclined trinocular viewing head, 360 degree rotatable; interpupillary distance 50-75mm, binocular=100:0 or 0:100 |
| Eyepiece | High eye point wide field plan eyepiece PL10X22mm, with adjustable diopter, reticle attachable High eye point wide field plan eyepiece PL15X16mm, with adjustable diopter |
| Objective | Long working distance plan achromatic metallurgical objectives 5X, 10X, 20X, 50X, 100X Long working distance bright & dark field plan achromatic metallurgical objectives 5X, 10X, 20X, 50X, 100X |
| Nosepiece | Inward quintuple bright field nosepiece (DIC slot), with built-in magnification sensor Inward quintuple bright & dark field nosepiece (DIC slot), with built-in magnification sensor |
| Frame | Reflected frame low-position coaxial focusing system, coarse range 9mm (up 6.5mm, down 2.5mm), fine precision 0.002mm; with upper limit and tension adjustment; with switch for bright and dark field; with variable field diaphragm and aperture diaphragm, both center adjustable; with slots for filters and polarizing kit; with light intensity indicator; with infrared induction; with magnification display |
| Illumination | External power adapter, input 100V-240V, output 15V13.4A, light intensity adjustable |
| Stage | Three layers rackless stage, size: 240mm (W) X 250mm (L), moving range: 50X 50mm; low-position handle knob |
| Camera adapter | 0.35X, 0.5X, 0.65X, 1X focusing C-mount |
| Others | Polarizer, fixed analyzer, 360 degree rotatable analyzer, DIC attachment, filters, high precision micrometer |
